Discharge Worktable, 20″ W x 48″ L with Stock Stop
Work Light, Wired In
Automatic Length Stop Assembly
Blade Break/Stall Switch
Hydraulic Chip Conveyor, Auger Style
Hydraulic Holddown, Saw Vise
Stock Stand, 6″ Wide (Heavy Duty)
Stock Stand, 12″ Wide (Heavy Duty)
High Speed Drive & Guide 400-3000 SFPM, ¾” Blade
Free Standing Roller Stock Conveyors, 6″ Centers:
18″ X 5′ X 2,500 lbs Cap. Distributed Weight
18″ X 10′ X 5,000 lbs Cap. Distributed Weight
Rectangular @ 45° 10″ High X 7½” Wide Round @ 45° 7½” Dia.
Voltage
208-60-3
230-60-3
460-60-3
575-60-3 (2HP)
Capacity: Rectangular @ 90° 10″ High x 17″ Wide, Round @ 90° 10″ Dia.
Weight capacity: 5,000 lbs
Blade speed: 60-500 SFPM
Blade size: 1″ X .035″ X 11′-11″
Blade guide: Carbide Block
Blade tension: Hydraulic, Console Controlled
Bandwheel size: 14½”
Vise: Hydraulic, Full Stroke
Blade drive: 5 HP, AC Vector Drive
Sawing force: Hydraulic 0-750 lbs
Coolant capacity: 15 Gallons
Hydraulic capacity: 20 Gallons
Hydraulic drive: 2 HP Motor
Work height: 26″
Shipping weight: 1,975 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 97″ Length x 49″ Width x 65″ Height
