Automatic Length Stop Assembly
Discharge Worktable, 20″ W x 48″ L with Stock Stop
Discharge Worktable, 30″ W x 48″ L with Stock Stop
Work Light, Wired In
Air Vise Manual
Air Holddown
Blade Break/Stall Switch
Chip Conveyor, Electric, Auger Style
High Speed AC Drive (1″ Blade) 400-3000 SFPM
Free Standing Roller Stock Conveyors, 6″ Centers:
21″ X 5′ X 5,000 lbs Cap. Distributed Weight
21″ X 10′ X 10,000 lbs Cap. Distributed Weight
31” x 5’ x 5,000 lbs Cap Distributed Weight
31” x 10’ x 10,000 lbs Cap Distributed Weight
21″ x 10′ Powered Conveyor, Electric
31” Powered Conveyor
Rectangular at 45° 16″ High X 13″ Wide, Round at 45° 13″ Diameter
Voltage
208-60-3
230-60-3
460-60-3
575-60-3 (5HP)
Capacity: Rectangular at 90° 16″ High x 30″ Wide, Round at 90° 16″ Diameter
Weight capacity: 5,000 lbs
Blade speed: 60-500 SFPM
Blade size: 1¼” X .042″ X 16’8″
Sawing feed: Variable, Hydraulic
Blade guide: Rollers and Carbide Side Blocks
Blade tension: Manual with Indicator
Bandwheel size: 20″
Vise: Manual, 8-1/2”
Blade drive: 7½ HP, 3ph, AC Vector Drive
Sawing force: 30-120 lbs
Coolant capacity: 15 Gallons
Hydraulic capacity: ¾ Gallon
Hydraulic drive: ⅓ HP Motor
Work height: 26″
Shipping weight: 2,500 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 118″ Length x 52″ Width x 88″ Height
