Automatic Length Stop Assembly
Discharge Worktable, 20” W x 48” L with Stock Stop
Discharge Worktable, 24” W x 48” L with Stock Stop
Work Light, Wired In
Air Vise, Manual
Air Holddown, Manual
Blade Break/Stall Switch
Electronic Chip Conveyor, Auger Style
High Speed Drive & Guides (1” Blade) 400-3000 SFPM
Free Standing Roller Stock Conveyors, 6” Centers
21”X 5′ X 5,000 lbs Cap. Distributed Weight
21” X 10′ X 10,000 lbs Cap. Distributed Weight
24” X 5’ X 5,000 lbs Cap. Distributed Weight
24” X 10’ X 10,000 lbs Cap. Distributed Weight
Electronic Powered Conveyor 21” X 10′
24” Powered Conveyor
H-2024-1
Voltage
208-60-3
230-60-3
460-60-3
575-60-3
Capacity: Rectangular at 90º 20” High x 24” Wide, Round at 90º 20” Diameter
Weight capacity: 5,000 lbs
Blade speed: 60-500 SFPM
Blade size: 1¼” X .042” X 17′ -8″
Blade guide: Rollers and Carbide Side Blocks
Blade tension: Manual with Indicator
Bandwheel size: 20”
Vise: Manual, 15”
Blade drive: 7½ HP, AC Vector Drive
Sawing force: 30-120 lbs
Coolant capacity: 15 Gallons
Hydraulic capacity: ¾ Gallon
Hydraulic drive: ⅓ HP Motor
Work height: 26”
Shipping weight: 2,800 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Shipping dimensions: 101”L x 40”W x 86”H
