Discharge Worktable 40″ W x 56″ L
Hydraulic Holddown, Saw Vise
Hydraulic Chip Conveyor
Blade Break/Stall Switch
Non-Powered Conveyor, 40″ X 5′
Non-Powered Conveyor, 40″ X 10′
Hydraulic Powered Conveyor, 40″ X 10′
High Speed Drive & Guides (1¼” Blade) 500-3000 SFPM
Rectangular at 45° 25″ High X 24″ Wide, Round at 45° 24″ Diameter
Blade Tension Indicator
Electronic Door Interlocks
Voltage
208-60-3
230-60-3
460-60-3
575-60-3
Capacity: Rectangular at 90° 25″ High X 40″ Wide, Round 25.5″ Diameter
Weight capacity: 15,000 lbs
Blade speed: 60-500 SFPM
Blade size: 1¼” X .042″ X 22′-6″
Blade guide: Carbide Blocks with Roller Backup
Blade tension: Hydraulic
Bandwheel size: 26″
Vise: Hydraulic
Blade drive: 7½ HP, AC Vector Drive
Sawing force: 0-750 lbs
Coolant capacity: 15 Gallons
Hydraulic capacity: 20 Gallons
Hydraulic drive: 2 HP Motor
Work height: 28″
Outfeed table: 24’ X 40”
Shipping weight: 5,800 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 161″ Length x 52″ Width x 100″ Height
