Model W-914A CNC
Have one to sell?
ConditionNew
1 available
New
Air Holddown, Saw & Barfeed Vise
Blade Tension Indicator
Electronic Auger Style Chip Conveyor
Discharge Worktable (20″ Wide x 48″ Long)
Work Light, Wired in
AC Drive Console Controlled Blade Speed
Free Standing Roller Stock Conveyors, 6″ Centers
18″ X 5′ X 2,500 lbs Cap Distributed Weight
18″ X 10′ X 5,000 lbs Cap. Distributed Weight
CNC Programmable Controller with Color Touch Screen
Machine Diagnostics & Programming Prompting
99+ Job Selection
Automatic Kerf Compensation
Blade Break/Stall Switch
Fork Lift Pockets in Base
Voltage
208-60-3
230-60-3
460-60-3
575-60-3
Capacity: Rectangular at 90° 9″ High x 14″ Wide Round 9″ Diameter
Weight capacity: 3,000 lbs
Blade speed: 70-380 SFPM
Blade size: 1″ X .035″ X 11′ 6″
Blade guide: Roller Guides with Carbide Inserts
Vise: Air, 8½” High
Bandwheel size: 14½”
Blade tension: Manual
Blade drive: 3 HP Variable Speed
Sawing force: 30-120 lbs
Coolant capacity: 15 Gallon
Hydraulic capacity: ¾ Gallon
Hydraulic drive: ¾ HP Motor
Work height: 35″
Barfeed projection: Hydraulic 0-25″ CNC Controlled
Projection accuracy: +/-.002″
Shuttle indexes: Unlimited
Remnant end: 8″
Tipoff worktable: 19½” Wide x 15½” Deep
Shipping weight: 2,400 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 82″ Length x 96″ Width x 68″ Height
