Model H-2024HAC-CNC (3° Cant)
Have one to sell?
ConditionNew
1 available
New
Hydraulic Holddown, Saw & Barfeed Vise
Hydraulic Auger Style Chip Conveyor
Discharge Worktable (24″ Wide x 48″ Long)
Work Light, Wired In
Extra Coolant Nozzle with Magnetic Base
High Speed Drive & Guides (1¼” Blade) 400-3000 SFPM
Free Standing Roller Stock Conveyors, 6″ Centers:
24″ X 5′ X 5,000 lbs Cap. Distributed Weight
24″ X 10′ X 10,000 lbs Cap. Distributed Weight
24” Powered Conveyors
Linear Rail Travers Head
CNC Programmable Controller with Color Touch Screen
500+ Job Selection
Automatic Kerf Compensation
Blade Break/Stall Switch
Bed and Vise Wear Strips
Voltage
208-60-3
230-60-3
460-60-3
575-60-3
Capacity: Rectangular @ 90° 19-½” H x 24″ W, Round at 90° 20″ Diameter
Weight capacity: 6,500 lbs
Blade speed: 60-500 SFPM
Blade size: 1½” X .050″ X 20’-0″
Blade guide: Roller Guides with Carbide Inserts
Vise: Hydraulic, Full Stroke, 15″ High
Bandwheel size: 22″
Blade tension: Hydraulic
Blade drive: 10 HP, AC Vector Drive
Sawing force: 0-750 lbs
Coolant capacity: 15 Gallons
Hydraulic capacity: 20 Gallons
Hydraulic drive: 2 HP Motor
Work height: 35″
Barfeed projection: 0-25″ CNC Controlled
Shuttle indexes: Unlimited
Projection accuracy: +/-.002″
Remnant end: 4″
Shipping weight: 5,500 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 122″ Length x 101″ Width x 93″ Height
