Model EVM-2030-6
Have one to sell?
ConditionNew
1 available
New
Voltage
208-60-3
230-60-3
Optional Voltage
460-60-3
Flood Coolant
Optional
Optional Accessories
208/230-60-3 Standard Voltage – Optional 460-60-3 Available
1¼” Bi-Metal Blade
Ball Screw Cutting Head Feed
Mist Coolant System – Sequenced
Minimal Power Consumption
Blade Break/Stall Detection
Electronic Controlled Blade Tension
0°-3° Forward Canted Frame Standard
Semi-Automatic Operation
Dual Direction 60° Miter cutting
Digital Cut Force
Digital Feed Rate
TEFC Motors
Fused Disconnect with Lock-Out
Digital Feed Position for Notch Cutting
Quick/Easy Blade Speed Change
COMING-SOON-300s
at 45° 20″ High X 20″ Diameter
at 60° 14″ High X 20″ Diameter
Capacity: at 90° 30″ High X 20″ Diameter
Weight capacity: 5,000 lbs
Blade speed: 30-500 SFPM
Blade size: 1¼” X .042″ X 18′-6″
Blade guide: Rollers with Carbide Blocks as Backup
Blade tension: Powered Electric Screw
Bandwheel size: 20″
Vise: Powered Electric Screw
Blade drive: 7½ HP, AC Vector Drive
Sawing force: 0-500 lbs w/Digital Readout
Coolant: Spray Mist
Angle control: Powered w/Digital Control
Controls: Color Touch Screen-PLC
Work height: 42″, 47.5” w/Flood Coolant Optional
Outfeed table: 24’ X 40”
Shipping weight: 4,000 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine dimensions: 100″ Length x 36″ Width x 130″ Height
