TANDEM AD-S 37220
Have one to sell?
ConditionNew
New
AD-S Press Brakes
AD-S Series press brakes, designed with high technology to increase efficiency on precise part bending. With Easy to use control unit, stabile body structure, perfect design, low operating cost, different tool usage options, maximum safety standards, DURMA press brake is the best in the world in its segment.
Bending performance is increased by using high quality European clamping system and easiness to use. DURMA is your solution partner with various tool options.
DURMA provides the best level of service and spare parts with qualified personnel and spare parts in stock. Therefore with DURMA press brakes you can always achieve perfect result.
AD-S Series Press Brake today, tomorrow and forever with you.
Bending Tonnage 220 metric 240 US
Bending Length 3700mm 146.67"
Distance Between Columns 3100mm 122.05"
Stroke 265mm 14.44"
Daylight 530mm 20.87"
Throat Depth:
Standard 450mm 17.72"
Optional 750mm 29.53"
Table Height 900mm 35.44"
Table Width 104mm 4.10"
Y Rapid Speed 160mm sec
Y Working Speed 10mm sec
Y Return Speed 120 sec
X As Working Speed 500mm sec
R Axes Working Speed 350mm sec
R Axes Working Distance 250mm 9.85"
X Axes Distance:
Standard 650mm 25.59"
X
X,R
X,R,Z1,Z2
Optional 750mm 29.53"
X,R,Z1,Z2
Optional 1000mm 39.37"
X,R
X,R,Z1,Z2
Motor power 22kw 30hp
Length 4950mm 194.89"
Width 1770mm 69.59"
Height 2900mm 114.18"
Weight Approx. 14360kg 31700lbs
